THE Machine Lab

Over 20 years of creating affordable mobile robot systems that help keep people out of harms way.

Featured Products

A remote inspection robot with tracks and a control unit in a protective case, along with a monitor, all set against a black and red hexagonal patterned background. The image displays product specifications and branding for a robotic inspection devic

Advertisement for the Micro Traxx Remote Inspection Robot by The Machine Lab Inc., featuring a rugged orange carrying case with a monitor, a remote control, and a tracked robot with orange accents. The ad lists specifications such as size, camera, au

Close-up of a robotic machine with tracks and mechanical arms, alongside a remote control device and a carrying case, set against a black background with red hexagonal patterns and technical diagrams. Text describes the machine's features and website

An advertisement for the Machine Lab Inc. showcasing a ruggedized digital handheld robot controller with a 7-inch LCD monitor, four camera multiplexing capability, two telemetries, and two robotic joysticks. The background features a black and red he

ROBOT SYSTEMS

.01

MMP 15 Basic

$3,350.00

The MMP-15 basic mobile platform is a rugged low profile tracked unit capable of carrying 15 pounds of payload with ease. There is a forward facing protected cut out in the chassis for mounting cameras or sensors. There is also an accessible rear battery bay for quickly swapping batteries.

The chassis is made of aluminum and the unit comes complete with high torque 52mm motors, motor controller, batteries, battery charger, power switch and LED fuel gauge.

Everything is wired and ready to go out of the box. The only thing necessary for operation is a control signal from a device such as an RC radio controller, micro-controller or computer. There are multiple control protocols that can be used including PWM, analog, RS-232 Serial and packetized RS-232 serial. This unit also has an optional set of encoders for the drive motors which can be interfaced with the included motor controller.

Weight: 15 lbs.
Payload: 20* lbs.
Speed: 5.4 ft./sec.
Runtime: 4 hrs.
Length 19"
Width 17"
Height 5.75"

All Machine Lab “Platform” products can easily be upgraded or customized. Just ask.

BASIC

Learn more

.02

MMP 40X Tactical

$0.00

The MMP-40X tactical robot system is a rugged and proven machine having been used for tactical operations by US law enforcement. This robot is medium to large sized machine that is extremely robust yet, at 100 pounds, can still be lifted and carried by one person. The robot is multi-terrain capable and can climb many types of stairs with no problem.

The MMP-40X-HD tactical robot has 3 cameras which include a forward facing color Pan/Tilt camera with IR illumination up to 20 feet in total darkness. There is also a wide angle color gripper camera and a wide angle color rear facing camera that perform well in low light conditions.

This robot platform can be fitted with many different accessories including 4, 5 and 6 axis manipulator arms that have the ability to open doors and lift from 8 to 25 pounds depending on the chosen arm. Other accessories include but are not limited to flood lights, spot lights, Infrared flood lights, payload bays, remote release trailers, sensor arrays, custom tools, additional cameras, ribbon lifts, scissor lifts, and folding telescoping boom arms.

Please see the specification sheet for more information.

Weight: 63 lbs.
Payload: 30 lbs.
Speed: 5.5 ft./sec.
Runtime: 4 hrs.

All Machine Lab “Platform” products can easily be upgraded or customized. Just ask.

CALL TO ORDER

TACTICAL

Learn more

.03

Glimpse

$17,500.00

This is our new commercial and residential inspection robot sysetm. The GLIMPSE robot is compact and can fit in very tight places where inspectors can't. With an HD 10X zoom camera and 1080p on-board recording capability you will get sharp images at the operator control unit as well as recorded HD videos and still images. The actuated flipper arms allow the GLIMPSE to negotiate debris and large obstacles that may be present during your inspection. The GLIMPSE can even self-right. It also has a rear facing camera and flood/spot lights on the front and rear of the robot.

Weight: 14 lbs.
Screen Size: 7-10 in.
Speed: 3.2 ft./sec.
Runtime: 1 hr.

INSPECTION

Learn more

.04

Arms

$0.00

The Machine Lab designs and manufactures robotic manipulator arms specifically for mobile robots and other custom applications. Arms are available with 4 or 6 axis of motion and possess a number of capabilities depending on the application. Manipulator arms come with electronic control modules with or without absolute position feedback. Inquire today about off-the-shelf models or customized arms for specific tasks.

Weight: 6-24 lbs.
Payload: 8-20 lbs.
Movement: 4-6 DOF.
Max Reach: 24-48 in.
